1. This integrated online and offline system works with EN series control boxes. When disconnected from a PC, it automatically switches to SD card master control (intelligent control system), offering flexibility and convenience.

2. When the SN-510 is used as an intelligent master control, simply replace the effects file on its SD card (file name modification is not supported) to change the effects of all EN control boxes in the same link.

3. When used as an offline master control, the SN-510 supports a maximum output of 40W per channel (including virtual points) and can control 154 EN sub-controllers. SN master control units can be expanded through master-slave cascading.

4. Optional additional features include time control, master-slave cascading synchronization, GPS synchronization, BTS synchronization, and DMX console control.

5. Includes professional effects creation software for custom effects.

Product Specifications: 285L × 156W × 45H (mm)

Casing Material: Iron

Input Voltage: AC 100V–240V

Cascade Signal: [Master/Slave] Optocoupler Signal Transmission, [PC-SN / SN-EN] SW 100M Ethernet Protocol

Load: 30W per channel

Network Port: Standard RJ45 Network Interface

Connectable EN Boxes: Up to 154

Operating Power: <10W

Operating Temperature: -15°C–60°C, Relative Humidity: ≤50%RH

Transmission Distance: Category 5e Unshielded Ethernet Cable, 100 meters between control boxes. For [SN Box Master/Slave Optocoupler Signal Transmission] transmission distances exceeding 100 meters, please add an AP100 to increase the distance. [Ethernet Protocol] For longer distances, use a fiber optic converter, up to 5 km.

Protection Rating: IP0 (not dustproof or waterproof)

Usage Environment: Please install in a dry indoor environment, away from dust, moisture, and rain.

Net Weight: 1300g
